Designed for versatility, the Mimosa C6 expands service reach by delivering reliable broadband in diverse deployment scenarios. Its advanced 20 dBi, 4x4 patch array antenna with beamforming, ensures strong performance in dense urban areas, suburban neighborhoods, and remote rural locations with complex terrain. By overcoming Line-of-Sight limitations, the C6 empowers service providers to connect hard-to-reach customers, unlocking new opportunities for network growth and bridging the digital divide.
C6
Redefining Connectivity Without Limits
The Mimosa C6 Non-Line-of-Sight Client Radio enables high-performance Point-to-Multipoint (PTMP) and Point-to-Point* (PTP) connectivity in challenging environments where clear Line of Sight (LOS) isn’t possible. With up to 2.5 Gbps throughput at the wireless interface and support for the 6 GHz spectrum**, the C6 overcomes obstacles to extend broadband access where traditional solutions fall short.
* Future software release
**6 GHz operation subject to country regulations; not yet available in the U.S.
Download Specs
Key Specs
2.5* at Wireless Interface
Gbps
Aggregate Speed
Non-Line-of-Sight
Link Distances
20
dBi
Gain
5.15 - 6.425
GHz
Frequency
2.5* at Wireless Interface
Gbps
Aggregate Speed
Non-Line-of-Sight
Link Distances
20
dBi
Gain
5.15 - 6.425
GHz
Frequency
Value
Price Performance Leader
Performance
Take PTMP to a New Level
The Mimosa C6 delivers exceptional performance with its advanced 4x4 patch array antenna, providing up to 20 dBi gain with beamforming for enhanced long-range Non-Line-of-Sight (NLOS) connectivity. With support for the 6 GHz spectrum*, the C6 maximizes reliability and minimizes interference, ensuring faster, more stable wireless broadband in challenging environments.
Design
Built to Last
Built for reliability, the Mimosa C6 features a durable IP67-rated design, ensuring it withstands the harshest environments. Engineered for carrier-grade performance, it incorporates advanced RF noise mitigation and leverages the low-noise 6 GHz band for cleaner, more dependable connectivity—even in challenging deployment scenarios.
Link Planning
Going the Distance
The Mimosa Design Tool simplifies PTP and PTMP connectivity evaluation by calculating expected performance and reliability with visual aids like terrain elevation . It provides precise installation reports and heatmap-based access point coverage planning, accounting for factors like weather and interference.
C6 FAQ
Dimensions
215 mm (Height) x 275 mm (Width) x 80 mm (Depth)
2.5 kg
Max Output Power
24 dBm
IP Rating
IP67
Absolutely! The C6 seamlessly integrates with Mimosa’s A6 Access Point and can be deployed alongside the C6x, giving operators the ultimate flexibility to tailor their networks with either a Line of Sight or Non-Line of Sight solution. Whether in dense urban environments, rugged rural terrain, or hard-to-reach locations, this combination empowers operators to scale efficiently while maximizing cost-performance.
The C6 supports Line-of-Sight (LOS), Near-Line-of-Sight (nLOS), and Non-Line-of-Sight (NLOS) connections. While NLOS performance varies by environment, the C6 leverages 4 spatial streams and 8T8R chains to enhance connectivity in obstructed conditions.
Although this is especially difficult to quantify for the broad range of nLOS and NLOS installations that the C6 will support, our network design tool (LINK) allows customers to view predicted performance and heat maps based on a wide range of factors.
Although Mimosa's initial support will be limited to PTMP, we anticipate releasing PTP support in the coming months to augment the PTP support provided by our C6x and B6x (Links) radios.
